Ohara Sk-1320 Synthetic Fused Silica

Product Item : RT20220509001#
Category： Materials
Type: Ohara Optical Substrate
Substrate: Ohara Sk-1320 Fused Silica
Substrate: Ohara Sk-1320 Fused Silica
Striae: Grade a in One Direction(as Per Mil-G-174)
Product description：Ohara Sk-1320 Synthetic Fused Silica/Ohara Optical Silica/Ohara Sk-1320/Ohara Quartz
INQUIRY

General Introduction: SK-1320 series of Ohara Quartz is a synthetic fused silica for the optics developed as the fused silica material for precise various optical components for the optics application and the high-power laser.
SK-1321(abbr.U1),-1322(abbr.U2) is guaranteed the homogeneity each in one direction and three directions.

Products Name: OHARA SK-1320 synthetic fused silica
Alias: OHARA SK-1320 glass, Ohara SK-1320 fused silica, Ohara SK-1320, Ohara SK-1320 VAD fused silica, Ohara SK-1320 synthetic fused silica, Ohara SK-1320 optical glass, OHARA SK-1320 quartz glass, SK-1320 Ohara fused silica, SK-1320 Ohara quartz, etc

Main Characteristics:

Serial Models	Max. size (mm)	Homogeneity*2
SK-1320L	600	-
SK-1321(U1)	250	1D2×10-6
SK-1321L(U1L)	250	1D2×10-6
SK-1322(U2)	250	3D2×10-6
SK-1322L(U2L)	150	3D2×10-6
SK-1300*5	600	-
SK-1310*5	600	-

Optical Qualities:

Item	Grade
Bubbles	0-0.03mm2/100cm3
Striae	Grade A in one direction(As per Mil-G-174)
Birefrengence(Strain)
SK-1320L	1D10
SK-1321(U1)	1D3
SK-1321L(U1L)	1D3
SK-1322(U2)	3D3
SK-1322L(U2L)	3D3
SK-1300*5	1D10
SK-1310*5	1D10

Physical Properties:

Item	Unit	Value
Density	g/cm3	2.20
Yong's Module	GPa	71.4
Poisson's ratio		0.17
Compression strength	GPa	1.1
Bending strength	MPa	69
Tensile strength	MPa	55
Torsional rigidity	GPa	30.9
Vickers hardness	GPa	8.8-10.1
Knoop hardness	Kg/mm2	6.4-7.0
Coefficient of thermal expansion	cm/cmºC	5.5*10-7
Softening point	ºC	1700
Annealing point	ºC	1160
Strain point	ºC	1060
Specific heat(26ºC)	kJ/kgK	0.74
Thermal conductivity ratio(26ºC)	cal/cm.sec.ºC	1.1
Thermal conductivity ratio(100ºC)	Cal/cm.sec.ºC	1.1

Main Applying Fields:

Applying Fields:	Optical Lens Optical Window Optical Mirror Optical Prism Optical Filters Optical Corner Cube Optical Beam Splitter Etalons Optical Brewster Optical Flat Optical High-power laser.
*****

Matching Custom Manufacturing Serivce:
Including Moulding, CNC machining, Polishing, Particle beam processing, Magnetic flux conversion processing, Grinding, Coating, Lightweighting, Custom Shaping, Counterbores, Drilling & Coring, Edge & Bevel Polishing,3D Contouring, Bevels & Chamfers, Steps & Slots, Laser Cutting & Marking, Metrology & Inspection, Precision Pitch Polishing, Double-Sided Polishing, Optical Assembly, Measuring, etc.
Matching processing equipments;
1).Single side lapping and polishing machines
2).Duble sided polishing machines
3).Ring throwing machines
4).DMG five-axis five-linkage spherical milling machine
5).DMG ultrasonic machining center
6).Super large scale gantry cnc machining center (2.0*2.0m)
7).Super large scale surface grinder (1.6m*1.6m)
8).CNC cutting machines
9).Thin plate cleaning machines
10).Ultrasonic trough cleaning machines
11).Plane interferometers
12).Two dimensional detectors
13).Ion beam polishing machines
14).Magnetorheological polishing equipments

Main Cooperation Materials Manufacturers:
CORNING, OHARA, SCHOTT, LEONI, AGC,HELLMA, NIKON,VITRON,C-LASER,ETC

Main Export Countries & Areas:
Usa, Uk, Japan, Germany, Spain, France, Swiss, Korea, Russia, Pakistan, India, Portugal, Canada, New Zealand, Australia, Saudi Arab, Turkey, Finland, Poland ,etc.
