N-Bk7 Right-Angle Prisms

Product Item : RT20220422001#
Category：
Substrate: Schott N-Bk7 Glass
Surface Quality: 60-40 Scratch-Dig or Custom Manufacturing
Surface Flatness: Lambda/2 at 632.8 Nm Over The Clear Aperture
Coating Type: Uncoated or Aluminized Hypotenuse
Product description：N-Bk7 Right-Angle Prisms/N-Bk7 Prism/Right-Angle Prism/Optical Prism
INQUIRY

General Introduction: Raytek right angle prism is usually used to turn the light path or deflect the image formed by the optical system by 90 degrees. According to the different orientations of the prism, the imaging can be the same left and right, but upside down and left and right are different. Right angle prism can also be used for image combination, beam offset and other applications.
When right angle prism is used, it is usually coated with some optical film. The right angle prism itself has a large contact area and a typical angle of 45 ° and 90 ° so it is easier to install and has better stability and strength to mechanical stress than ordinary mirrors. They are the best choice for all kinds of optical devices and instruments

Products Name: Economy N-BK7 Right-Angle Prisms
Alias: N-BK7 right angle prism, Right angle prism, right angle optical prism, high precision right angle prism,N-BK7 prism,etc

Prism Substrates:
N-BK7

Optional I:	N-BK7 from CORNING, OHARA, SCHOTT, LEONI, AGC,HELLMA, NIKON,VITRON,ETC
Optional II:	Equivalent N-BK7 Made in China, C-laser own brands

Coating:
Uncoated
Or Aluminized bevel

Main Applying:

Applying Fields I:	Image combination, beam offset and other applications
Applying Fields II:	Optical components for various devices and instruments
*****

Main Optical Tech Specification:

Prism Shape	Right-angle prism	Size Tolerance	+0/-0.25 mm
Prism Material	N-BK7	Thickness Tolerance
Coating Type	Uncoated Or Aluminized Hypotenuse	Chamfers	0.25-0.50 mm face width
Damage Threshold	Aluminum hypotenuse: 100 W/cm2 CW, 10 mJ/cm2 with 10 nsec pulses, typical	Chamfers Angle Tolerance	45°
Surface Accuracy Irregularity		Thermal limit	-
Surface Quality	60-40 scratch-dig	Coefficient of thermal expansion	-
Surface Flatness	λ/2 at 632.8 nm over the clear aperture	Parallelism	-
Wavelength Region	Visible and NIR	Clear Aperture	≥ central 85%
OEM/ODM	Accepted	Custom Manufacturing	Available

Main Cooperation Materials Manufacturers:
CORNING, OHARA, SCHOTT, LEONI, AGC,HELLMA, NIKON,VITRON,C-LASER,ETC

Main Export Countries & Areas:
Usa, Uk, Japan, Germany, Spain, France, Swiss, Korea, Russia, Pakistan, India, Portugal, Canada, New Zealand, Australia, Saudi Arab, Turkey, Finland, Poland ,etc.
